Introduction

Observability in Kubernetes requires coordinated implementation of metrics, logs, and traces. This guide walks through building a production-ready observability stack using proven open-source tools.

The Three Pillars

Metrics

Numerical measurements over time:

CPU, memory, network utilization
Request rates and latencies
Business KPIs

Logs

Discrete events with context:

Application logs
System logs
Audit logs

Traces

Request flow across services:

Distributed transaction tracking
Latency breakdown
Dependency mapping

Stack Components

Metrics: Prometheus + Grafana

Prometheus for collection and storage:

Pull-based metrics collection
PromQL query language
Built-in alerting

Grafana for visualization:

Powerful dashboards
Multi-data-source support
Alerting integration

Logs: Loki + Promtail

Loki for log aggregation:

Prometheus-inspired design
Label-based indexing
Cost-effective storage

Promtail for collection:

Automatic Kubernetes discovery
Pipeline processing
Label enrichment

Traces: Tempo + OpenTelemetry

Tempo for trace storage:

Scales to millions of traces
Object storage backend
TraceQL query language

OpenTelemetry for instrumentation:

Vendor-neutral
Auto-instrumentation
Unified collection

Implementation

Step 1: Deploy Prometheus Stack

Using Helm:

helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo update

helm install prometheus prometheus-community/kube-prometheus-stack \
  --namespace monitoring \
  --create-namespace \
  --set grafana.adminPassword=your-secure-password

Key configurations:

# values.yaml
prometheus:
  prometheusSpec:
    retention: 30d
    storageSpec:
      volumeClaimTemplate:
        spec:
          storageClassName: fast-ssd
          resources:
            requests:
              storage: 100Gi

    serviceMonitorSelector: {}
    podMonitorSelector: {}

grafana:
  persistence:
    enabled: true
    size: 10Gi

Step 2: Deploy Loki Stack

helm install loki grafana/loki-stack \
  --namespace monitoring \
  --set promtail.enabled=true \
  --set loki.persistence.enabled=true \
  --set loki.persistence.size=50Gi

Configure Promtail for Kubernetes:

# promtail-config.yaml
scrape_configs:
  - job_name: kubernetes-pods
    kubernetes_sd_configs:
      - role: pod
    relabel_configs:
      - source_labels: [__meta_kubernetes_pod_label_app]
        target_label: app
      - source_labels: [__meta_kubernetes_namespace]
        target_label: namespace
    pipeline_stages:
      - json:
          expressions:
            level: level
            message: msg
      - labels:
          level:

Step 3: Deploy Tempo

helm install tempo grafana/tempo \
  --namespace monitoring \
  --set tempo.storage.trace.backend=s3 \
  --set tempo.storage.trace.s3.bucket=traces-bucket

Step 4: Configure OpenTelemetry

Deploy the collector:

apiVersion: v1
kind: ConfigMap
metadata:
  name: otel-collector-config
  namespace: monitoring
data:
  config.yaml: |
    receivers:
      otlp:
        protocols:
          grpc:
          http:

    processors:
      batch:
        timeout: 5s

    exporters:
      otlp:
        endpoint: tempo.monitoring:4317
        tls:
          insecure: true
      prometheus:
        endpoint: "0.0.0.0:8889"

    service:
      pipelines:
        traces:
          receivers: [otlp]
          processors: [batch]
          exporters: [otlp]
        metrics:
          receivers: [otlp]
          processors: [batch]
          exporters: [prometheus]

Step 5: Connect Data Sources in Grafana

Add data sources:

Enable correlation:

# Grafana data source config
datasources:
  - name: Prometheus
    type: prometheus
    url: http://prometheus-server:80
    jsonData:
      httpMethod: POST

  - name: Loki
    type: loki
    url: http://loki:3100
    jsonData:
      derivedFields:
        - datasourceUid: tempo
          matcherRegex: "traceID=(\w+)"
          name: TraceID
          url: '${__value.raw}'

  - name: Tempo
    type: tempo
    url: http://tempo:3100

Application Instrumentation

Automatic Instrumentation

For Java applications:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-java-app
spec:
  template:
    metadata:
      annotations:
        instrumentation.opentelemetry.io/inject-java: "true"

Manual Instrumentation

For custom metrics:

import (
    "github.com/prometheus/client_golang/prometheus"
)

var requestsTotal = prometheus.NewCounterVec(
    prometheus.CounterOpts{
        Name: "http_requests_total",
        Help: "Total HTTP requests",
    },
    []string{"method", "path", "status"},
)

func init() {
    prometheus.MustRegister(requestsTotal)
}

Alerting Configuration

Prometheus Alerting Rules

apiVersion: monitoring.coreos.com/v1
kind: PrometheusRule
metadata:
  name: application-alerts
spec:
  groups:
    - name: application
      rules:
        - alert: HighErrorRate
          expr: |
            sum(rate(http_requests_total{status=~"5.."}[5m]))
            / sum(rate(http_requests_total[5m])) > 0.05
          for: 5m
          labels:
            severity: critical
          annotations:
            summary: High error rate detected

Dashboards

Essential dashboards:

Cluster Overview: Node health, resource utilization
Namespace View: Per-namespace metrics
Service Dashboards: RED metrics per service
enterprise-ai-infrastructure-gpu-clusters-cloud-services" title="Building Enterprise AI Infrastructure: GPU Clusters vs Cloud Services" class="internal-link">Infrastructure: Storage, infiniband-ethernet-ai-workloads" title="GPU Cluster Networking: InfiniBand vs Ethernet for AI Workloads" class="internal-link">networking

Conclusion

A comprehensive observability stack enables faster troubleshooting and better understanding of system behavior. Start with metrics, add logs for context, and implement tracing for distributed systems visibility.
